Introduction to Web
Development
HTML + CSS +
Javascript
Goals
Introduction to web
technologies:
● HTML to create the
document structure and
content
● CSS to control is visual
aspect
● Javascript for interactivity
Tools
What do we need to start:
● a good web-browser (Chrome or
Firefox)
● a good text editor like:
○ VSCode (cross platform)
○ Notepad++ (win)
○ textWrangler (osx)
○ sublime text (cross platform)
○ ecode (cross platform)
● the example HTML code to start
How can I test my code
Just open the index.html from the template in your text editor and
in your browser.
When you do any change to the code, check it in the browser by
pressing F5 (refresh site)
To open the developer tools press:
Windows: Control + Shift + I or
OSX: Command + Opt + I
Other tools are online editors like scratchpad or htmledit
Anatomy of a Browser
Inside a browser
Browsers have very differentiate
parts.
We are interested in two of them:
● the Rendering Engine (in charge
of transforming our HTML+CSS
in a visual image).
● The Javascript Interpreter
(also known as VM), in charge
of executing the Javascript
code.
Technologies
● HTML
● CSS
● Javascript
Browsers as a renderer
Browser's act as a renderer that takes
documents and construct a visual
representation of them.
Starting with the most simple one, a text
document, it will try to visualize it.
You can try, drop any .txt file into your
browser to visualize it.
The problem is that text documents without any
formatting tend to be hard to read for the user
(and quite boring).
That's why HTML was created, to give text
some format.
Markup language
There are many markup languages
that add special tags into the text
that the renderer wont show but use
to know how to display the text.
In HTML this tags use the next
notation:
My name is <b>Javi</b>
HTML
HTML means Hyper Text Markup
Language.
The HTML allow us to define the structure of a document
or a website.
HTML is NOT a programming language, it’s a markup
language, which means its purpose is to give structure to
the content of the website, not to define an algorithm.
It is a series of nested tags (it is a subset of XML) that contain
all the website information (like texts, images and videos).
Here is an example of tags:
<title>This is a title</title>
The HTML defines the page structure. A website can have
several HTMLs to different pages.
<html>
<head>
</head>
<body>
<div>
<p>Hi</p>
</div>
</body>
</html>
HTML: basic rules
Some rules about HTML:
● It uses XML syntax (tags with attributes, can contain other tags).
<tag_name attribute="value"> content </tag_name>
● It stores all the information that must be shown to the user.
● There are different HTML elements for different types of information and
behaviour.
● The information is stored in a tree-like structure (nodes that contain nodes inside)
called DOM (Document Object Model).
● It gives the document some semantic structure (pe. this is a title, this is a section,
this is a form) which is helpful for computers to understand websites content.
● It must not contain information related to how it should be displayed (that
information belongs to the CSS), so no color information, font size, position, etc.
HTML: syntax example
<div id="main">
<!-- this is a comment -->
This is text without a
tag.
<button class="mini">press
me</button>
<img src="me.png" />
</div>
HTML: syntax example
<div id="main">
<!-- this is a comment -->
This is text without a
tag.
<button class="mini">press
me</button>
<img
src="me.png" />
</div>
Tag
name attribute
s
commen
t
text
tag
self-closing
tag
DOM is a tree
Every node can only have
one parent, and every
node can have several
children, so the structure
looks like a tree.
Introduction to HTML-CSS-Javascript.pptx
Although there are lots of tags in the HTML specification, 99% of the webs use a
subset of HTML tags with less that 10 tags, the most important are:
● <div>: a container, usually represents a rectangular area with information inside.
● <img/>: an image
● <a>: a clickable link to go to another URL
● <p>: a text paragraph
● <h1>: a title (h2,h3,h4 are titles of less importance)
● <input>: a widget to let the user introduce information
● <style> and <link>: to insert CSS rules
● <script>: to execute Javascript
● <span>: a null tag (doesn't do anything), good for tagging info
HTML: main tags
HTML: other interesting tags
There are some tags that could be useful
sometimes:
● <button>: to create a button
● <audio>: for playing audio
● <video>: to play video
● <canvas>: to draw graphics from javascript
● <iframe>: to put another website inside ours
HTML: wrapping the info
We use HTML tags to wrap
different information on our site.
The more structure has the information,
the easier will be to access it and present
it.
We can change the way the information is
represented on the screen depending on
the tags where it is contained, so we
shouldn't be worried about using too
many tags.
HTML: tagging correctly
Try to avoid doing this:
<div
>
Titl
e
Here is some
content Here is
more content
</div>
Do this
instead
<div>
<h1>Title</h1>
<p>Here is content.</p>
<p>Here is more
content</p>
</div>
DONT DO THIS
HTML good use
It is good to have all the information properly wrapped in tags that give it some
semantics.
We also can extend the code semantics by adding extra attributes to the tags:
● id: tells a unique identifier for this tag
● class: tells a generic identifier for this tag
<div id="profile-picture" class="mini-image">...</div>
HTML references
HTML Reference: a description of all HTML tags.
The 25 Most used tags: a list with information of the more
common tags.
HTML5 Good practices: some tips for starters
Technologie
s
● HTML
● CSS
● Javascript
CSS
CSS allows us to specify how to
present (render) the document info
stored in the HTML.
Thanks to CSS we can control all the
aspects of the visualization and some
other features:
● Colors: content, background,
borders
● Margins: interior margin,
exterior margin
● Position: where to put it
● Sizes: width, height
● Behaviour: changes on mouse
over
CSS example
* {
color: blue; /*a comment
*/ margin: 10px;
font: 14px Tahoma;
}
This will change all the tags in my web ( ‘*‘ means all) to look blue with font Tahoma
with 14px, and leaving a margin of 10px around.
CSS fields
Here is a list of the most common CSS fields and an example:
● color: #FF0000; red; rgba(255,00,100,1.0); //different ways to
specify colors
● background-color: red;
● background-image: url('file.png');
● font: 18px 'Tahoma';
● border: 2px solid black;
● border-top: 2px solid red;
● border-radius: 2px; //to remove corners and make them more round
● margin: 10px; //distance from the border to the outer elements
● padding: 2px; //distance from the border to the inner elements
● width: 100%; 300px; 1.3em; //many different ways to specify
distances
● height: 200px;
● text-align: center;
● box-shadow: 3px 3px 5px black;
● cursor: pointer;
● display: inline-block;
● overflow: hidden;
CSS how to add it
There are four ways to add CSS rules to your website:
● Inserting the code inside a style tag
<style>
p { color: blue }
</style>
● Referencing an external CSS file
<link href="style.css"
rel="stylesheet" />
● Using the attribute style on a tag
<p style="color: blue; margin: 10px">
● Using Javascript (we will see this one later).
CSS selectors
Let's start by changing the background color of one tag of our website:
div {
background-color: red;
}
This CSS rule means that every tag DIV found in our website should have a red
background color. Remember that DIVs are used mostly to represent areas of our
website.
We could also change the whole website background by affecting the tag body:
body {
background-color: red;
}
CSS selectors
What if we want to change one specific tag (not all the tags of the same type).
We can specify more precise selectors besides the name of the tag. For instance, by
class or id. To specify a tag with a given class name, we use the dot:
p.intro {
color: red;
}
This will affect only the tags p with class name intro:
<p class="intro">
CSS Selectors
There are several selectors we can use to narrow our rules to very specific tags of our
website.
The main selectors are:
● tag name: just the name of the tag
○ p { ... } //affects to all <p> tags
● dot (.): affects to tags with that class
○ p.highlight { ... } //affects all <p> tags with
class="highlight"
● sharp character (#): specifies tags with that id
○ p#intro { ... } //affects to the <p> tag with the id="intro"
● two dots (:): behaviour states (mouse on top)
○ p:hover { ... } //affects to <p> tags with the mouse over
● brackets ([attr='value']): tags with the attribute attr with the value 'value'
○ input[type="text"] {...} // affects to the input tags of the
type text
CSS Selectors
You can also specify tags by its context, for example: tags that are inside of tags
matching a selector. Just separate the selectors by an space:
div#main p.intro { ... }
This will affect to the p tags of class intro that are inside the tag div of id main
<div id="main">
<p class="intro">....</p> ← Affects this one
</div>
<p class="intro">....</p>← but not this one
CSS Selectors
And you can combine selectors to narrow it down more.
div#main.intro:hover { ... }
will apply the CSS to the any tag div with id main and class intro if the mouse is over.
And you do not need to specify a tag, you can use the class or id selectors without
tag, this means it will affect to any node of id main
#main { ... }
CSS Selectors
If you want to select only elements that are direct child of one element (not that
have an ancestor with that rule), use the > character:
ul.menu > li { ... }
Finally, if you want to use the same CSS actions to several selectors, you can use
the comma , character:
div, p { … } ← this will apply to all divs and p tags
HTML arrange
It is important to understand how the
browser arranges the elements on the
screen.
Check this tutorial where it explains the
different ways an element can be
arranged on the screen.
You can change the way elements
are arranged using the display
property:
div { display: inline-block;
}
Box Model
It is important to note that by default any
width and height specified to an element
will not take into account its margin, so a
div with width 100px and margin 10px will
measure 120px on the screen, not 100px.
This could be a problem breaking
your layout.
You can change this behaviour changing
the box model of the element so the
width uses the outmost border:
div { box-sizing: border; }
Layout
One of the hardest parts of CSS is
construing the layout of your website
(the structure inside the window) .
By default HTML tends to put
everything in one column, which is not
ideal.
There has been many proposals in CSS
to address this issue (tables, fixed divs,
flex, grid, …).
Flexbo
x
The first big proposal to address the
layout was the flexbox model.
This model allows to arrange stuff in
one direction (vertically or
horizontally) very easily.
You can even choose to arrange from
right to left (reverse).
It can also be used to arrange a series
of elements in different rows.
Check the tutorial for more
info.
HTML
<div class="box">
<div>One</div>
<div>Two</div>
<div>Three
<br>first line
<br>second line
</div>
</div>
CSS
.box {
display: flex;
}
Grid
system
Because most sites are structured in a
grid, I recommend to use the CSS Grid
system.
We just assign how many rows/columns a div
should use from the main grid and it will
arrange automatically.
Check this tutorial to create the site
structure easily
HTML
<div class="grid-container">
<div class="grid-item1">1</div>
<div class="grid-item2">2</div>
</div>
CSS
.grid-container
{ display:
grid;
grid-template-
rows: 100px
100px;
grid-template-columns: 100px 100px
100px; grid-gap: 5px;
}
.grid-item1
{ background:
blue;
border: black 5px
solid;
grid-column-
start: 1;
Fullscreen
divs
Sometimes we want to have a div that
covers the whole screen (to make a
webapp), instead of a scrolling website
(more like regular documents).
In that case remember to use percentages
to define the size of elements, but keep in
mind that percentages are relative to the
element's parent size, so you must set the
size to the
<body> and <html> element to use 100%.
CSS
html, body {
width: 100%;
height: 100%;
}
div {
margin: 0;
padding: 0;
}
#main {
width: 100%;
height: 100%;
}
Trick to center
Centering divs can be hard sometimes, use this
trick:
.horizontal-and-vertical-
centering { display: flex;
justify-content: center;
align-items: center;
}
CSS further reading
There are many more rules for selectors.
Check some of the links to understand them
better. One line layouts tutorials
Understanding the Box Model: a good explanation of how to position the information
on your document.
All CSS Selectors: the CSS selectors specification
page. CSS Transition: how to make animations just
using CSS TailwindCSS: a CSS Framework
Technologies
● HTML
● CSS
● Javascript
Interactivit
y
Once the web was already being
used they realize people wanted to
interact with the websites in a more
meaningful way.
So they added an Interpreter to
execute a script language that could
modify the content of the web
dynamically.
Brendan Eich was tasked to develop it
in one week and it has become one of
the most important languages.
Javascript
A regular programming language, easy to start,
hard to master.
Allows to give some interactivity to the elements on the
web.
Syntax similar to C or Java but with no
types.
You can change the content of the HTML or the CSS
applied to an element.
You can even send or retrieve information from the
internet to update the content of the web without
reloading the page.
var my_number = 10;
function say( str )
{
console.log( str );
}
say("hello");
Javascript: insert code
There is three ways to execute javascript code in a website:
● Embed the code in the HTML using the <script> tag.
<script> /* some code */ </script>
● Import a Javascript file using the <script> tag:
<script src="file.js" />
● Inject the code on an event inside a tag:
<button onclick="javascript: /*code*/">press
me</button>
Javascript: Syntax
Very similar to C++ or Java but much simpler.
var my_number = 10; //this is a
comment var my_string = "hello";
var my_array = [10,20,"name",true];
var my_object = { name: "javi",
city: "Barcelona" };
function say( str )
{
for(var i = 0; i < 10; ++i)
console.log(" say: " + str
);
Javascript example
<html>
<body>
<h1>This is a title</h1>
<script>
var title = document.querySelector("h1");
title.innerHTML = "This is another title";
</script>
</body>
</html>
Javascript API
Javascript comes with a rich API to do many things like:
● Access the DOM (HTML nodes)
● Do HTTP Requests
● Play videos and sounds
● Detect user actions (mouse move, key pressed)
● Launch Threads
● Access the GPU, get the Webcam image, ...
And the API keeps growing with every new update of the
standard. Check the WEB API reference to know more
Javascript: retrieving element
You can get elements from the DOM (HTML tree) using different
approaches.
● Crawling the HTML tree (starting from the body, and traversing its
children)
● Using a selector (like in CSS)
● Attaching events listeners (calling functions when some
actions are performed)
Javascript: crawling the DOM
From javascript you have different variables that you can access to
get information about the website:
● document: the DOM information (HTML)
● window: the browser window
The document variable allows to crawl the tree:
document.body.children[0] // returns the first node inside
body tag
Javascript: using selectors
You can retrieve elements using selectors:
var nodes = document.querySelectorAll("p.intro");
will return an array with all <p class="intro"> nodes in the
web. Or if we have already a node and we want to search inside:
var node = mynode.querySelectorAll("p.intro")
Javascript: modify nodes
From JS you can change the attributes
mynode.id = "intro"; //sets an id
mynode.className = "important"; //set
class
mynode.classList.add("good"); //to add
to the current classes
Change the content
mynode.innerHTML = "<p>text to
show</p>"; //change content
Modify the style (CSS)
mynode.style.color = "red"; //change
any css properties
or add the behaviour of a node
Javascript: create nodes
Create elements:
var element = document.createElement("div");
And attach them to the DOM:
document.querySelector("#main").appendChild( elemen
t );
Or remove it from its parent:
element.remove();
You can clone an element also easily:
var cloned = element.cloneNode(true);
Javascript: hide and show
elements
Sometimes it may be useful to hide one element or show another.
You can change an element CSS directly by accessing its property
style. To avoid being displayed on the web change display to "none"
element.style.display = "none"; //hides elements from being
rendered element.style.display = ""; //displays it again
Using Inputs
If you want the user to be able to input some text we use the tag
<input>:
<input type="text"/>
There are other inputs, you can check this list.
From Javascript we can attach events like "click" or
"keydown". To read or modify the content of the input:
my_input_element.value = ""; //this will clear the text
inside the input
Example of a
website
HTML in index.html
<link href="style.css" rel="stylesheet"/>
<h1>Welcome</h1>
<p>
<button>Click me</button>
</p>
<script src="code.js"/>
CSS in style.css
h1 { color: #333;
} button {
border: 2px solid
#AAA; background-
color: #555;
}
Javascript in code.js
//fetch the button from the DOM
var button = document.querySelector("button");
//attach and event when the user clicks
it button.addEventListener("click",
myfunction);
//create the function that will be called
when the button is pressed
function myfunction()
{
//this shows a popup
window alert("button
clicked!");
}
Execution flow
It is important to have a clear
understanding of the execution
flow of your code.
Scripts are executed when the html
is being parsed.
Be careful accessing the DOM as the
DOM won’t contain all until all the
HTML is parsed.
It is good practice to start your code
with an init function called at the end
of your HTML.
<script>
var main =
document.querySelector("#main");
//main here is null, as the element does
//exist yet
</script>
<div id="main"></div>
<script>
var main =
document.querySelector("#main");
//main now is the right element
</script>
Further info
API References: DevDocs.io
Selectors: MDN
Tutorial To learn
Javascript.
http://codeacademy.co
m
To learn jQuery:
Thank You!!!!!

More Related Content

Similar to Introduction to HTML-CSS-Javascript.pptx (20)

Introduction to HTML+CSS+Javascript.pptx
Introduction to HTML+CSS+Javascript.pptxIntroduction to HTML+CSS+Javascript.pptx
Introduction to HTML+CSS+Javascript.pptx
wowiw65045

Introduction to HTML+CSS+Javascript.pptx
Introduction to HTML+CSS+Javascript.pptxIntroduction to HTML+CSS+Javascript.pptx
Introduction to HTML+CSS+Javascript.pptx
yashsharmaa0209

PPT ON SEMINAR REPORT.pptx. bhvhvhchchvhchch
PPT ON SEMINAR REPORT.pptx. bhvhvhchchvhchchPPT ON SEMINAR REPORT.pptx. bhvhvhchchvhchch
PPT ON SEMINAR REPORT.pptx. bhvhvhchchvhchch
yashsharmaa0209

Web Design & Development - Session 2
Web Design & Development - Session 2Web Design & Development - Session 2
Web Design & Development - Session 2
Shahrzad Peyman

Workshop 2 Slides.pptx
Workshop 2 Slides.pptxWorkshop 2 Slides.pptx
Workshop 2 Slides.pptx
DaniyalSardar

Html-Prabakaran
Html-PrabakaranHtml-Prabakaran
Html-Prabakaran
DrPrabakaranPerumal

Class1slides
Class1slidesClass1slides
Class1slides
Alexis Goldstein

Introduction to HTML+CSS+Javascript by Deepu.pptx
Introduction to HTML+CSS+Javascript by Deepu.pptxIntroduction to HTML+CSS+Javascript by Deepu.pptx
Introduction to HTML+CSS+Javascript by Deepu.pptx
deepuranjankumar08

Introduction to HTML.pptx
Introduction to HTML.pptxIntroduction to HTML.pptx
Introduction to HTML.pptx
VaibhavSingh887876

HTML & CSS.ppt
HTML & CSS.pptHTML & CSS.ppt
HTML & CSS.ppt
vaseemshaik21

HTML and CSS Basics
HTML and CSS BasicsHTML and CSS Basics
HTML and CSS Basics
Lindsey Meadows

Introduction to Cascading Style Sheets .
Introduction to Cascading Style Sheets .Introduction to Cascading Style Sheets .
Introduction to Cascading Style Sheets .
monishedustu07

Introduction to HTML+CSS+Javascript.pptx
Introduction to HTML+CSS+Javascript.pptxIntroduction to HTML+CSS+Javascript.pptx
Introduction to HTML+CSS+Javascript.pptx
deepuranjankumar2002

HTML_Training_101
HTML_Training_101HTML_Training_101
HTML_Training_101
John Robey

PHP HTML CSS Notes
PHP HTML CSS  NotesPHP HTML CSS  Notes
PHP HTML CSS Notes
Tushar Rajput

Thinkful - Frontend Crash Course - Intro to HTML/CSS
Thinkful - Frontend Crash Course - Intro to HTML/CSSThinkful - Frontend Crash Course - Intro to HTML/CSS
Thinkful - Frontend Crash Course - Intro to HTML/CSS
TJ Stalcup

2 INTRO TO HTML.pptx
2 INTRO TO HTML.pptx2 INTRO TO HTML.pptx
2 INTRO TO HTML.pptx
CHEYSERCHARRESEGATCH1

Introduction to Web Technologies PPT.pptx
Introduction to Web Technologies PPT.pptxIntroduction to Web Technologies PPT.pptx
Introduction to Web Technologies PPT.pptx
Kunal Kalamkar

Web Information Systems Html and css
Web Information Systems Html and cssWeb Information Systems Html and css
Web Information Systems Html and css
Artificial Intelligence Institute at UofSC

Introduction to HTML and CSS
Introduction to HTML and CSSIntroduction to HTML and CSS
Introduction to HTML and CSS
Mario Hernandez

Introduction to HTML+CSS+Javascript.pptx
Introduction to HTML+CSS+Javascript.pptxIntroduction to HTML+CSS+Javascript.pptx
Introduction to HTML+CSS+Javascript.pptx
wowiw65045

Introduction to HTML+CSS+Javascript.pptx
Introduction to HTML+CSS+Javascript.pptxIntroduction to HTML+CSS+Javascript.pptx
Introduction to HTML+CSS+Javascript.pptx
yashsharmaa0209

PPT ON SEMINAR REPORT.pptx. bhvhvhchchvhchch
PPT ON SEMINAR REPORT.pptx. bhvhvhchchvhchchPPT ON SEMINAR REPORT.pptx. bhvhvhchchvhchch
PPT ON SEMINAR REPORT.pptx. bhvhvhchchvhchch
yashsharmaa0209

Web Design & Development - Session 2
Web Design & Development - Session 2Web Design & Development - Session 2
Web Design & Development - Session 2
Shahrzad Peyman

Workshop 2 Slides.pptx
Workshop 2 Slides.pptxWorkshop 2 Slides.pptx
Workshop 2 Slides.pptx
DaniyalSardar

Introduction to HTML+CSS+Javascript by Deepu.pptx
Introduction to HTML+CSS+Javascript by Deepu.pptxIntroduction to HTML+CSS+Javascript by Deepu.pptx
Introduction to HTML+CSS+Javascript by Deepu.pptx
deepuranjankumar08

Introduction to Cascading Style Sheets .
Introduction to Cascading Style Sheets .Introduction to Cascading Style Sheets .
Introduction to Cascading Style Sheets .
monishedustu07

Introduction to HTML+CSS+Javascript.pptx
Introduction to HTML+CSS+Javascript.pptxIntroduction to HTML+CSS+Javascript.pptx
Introduction to HTML+CSS+Javascript.pptx
deepuranjankumar2002

HTML_Training_101
HTML_Training_101HTML_Training_101
HTML_Training_101
John Robey

Thinkful - Frontend Crash Course - Intro to HTML/CSS
Thinkful - Frontend Crash Course - Intro to HTML/CSSThinkful - Frontend Crash Course - Intro to HTML/CSS
Thinkful - Frontend Crash Course - Intro to HTML/CSS
TJ Stalcup

Introduction to Web Technologies PPT.pptx
Introduction to Web Technologies PPT.pptxIntroduction to Web Technologies PPT.pptx
Introduction to Web Technologies PPT.pptx
Kunal Kalamkar

Introduction to HTML and CSS
Introduction to HTML and CSSIntroduction to HTML and CSS
Introduction to HTML and CSS
Mario Hernandez


Recently uploaded (20)

Application Security and Secure Software Development Lifecycle
Application  Security and Secure Software Development LifecycleApplication  Security and Secure Software Development Lifecycle
Application Security and Secure Software Development Lifecycle
DrKavithaP1

MODULE 4 BUILDING PLANNING AND DESIGN SY BTECH HVAC SYSTEM IN BUILDING
MODULE 4 BUILDING PLANNING AND DESIGN SY BTECH HVAC SYSTEM IN BUILDINGMODULE 4 BUILDING PLANNING AND DESIGN SY BTECH HVAC SYSTEM IN BUILDING
MODULE 4 BUILDING PLANNING AND DESIGN SY BTECH HVAC SYSTEM IN BUILDING
Dr. BASWESHWAR JIRWANKAR

[HIFLUX] Lok Fitting&Valve Catalog 2025 (Eng)
[HIFLUX] Lok Fitting&Valve Catalog 2025 (Eng)[HIFLUX] Lok Fitting&Valve Catalog 2025 (Eng)
[HIFLUX] Lok Fitting&Valve Catalog 2025 (Eng)
하이플럭스 / HIFLUX Co., Ltd.

ISO 4548-7 Filter Vibration Fatigue Test Rig Catalogue.pdf
ISO 4548-7 Filter Vibration Fatigue Test Rig Catalogue.pdfISO 4548-7 Filter Vibration Fatigue Test Rig Catalogue.pdf
ISO 4548-7 Filter Vibration Fatigue Test Rig Catalogue.pdf
FILTRATION ENGINEERING & CUNSULTANT

ISO 5011 Air Filter Catalogues .pdf
ISO 5011 Air Filter Catalogues      .pdfISO 5011 Air Filter Catalogues      .pdf
ISO 5011 Air Filter Catalogues .pdf
FILTRATION ENGINEERING & CUNSULTANT

Enhanced heart disease prediction using SKNDGR ensemble Machine Learning Model
Enhanced heart disease prediction using SKNDGR ensemble Machine Learning ModelEnhanced heart disease prediction using SKNDGR ensemble Machine Learning Model
Enhanced heart disease prediction using SKNDGR ensemble Machine Learning Model
IRJET Journal

Axial Capacity Estimation of FRP-strengthened Corroded Concrete Columns
Axial Capacity Estimation of FRP-strengthened Corroded Concrete ColumnsAxial Capacity Estimation of FRP-strengthened Corroded Concrete Columns
Axial Capacity Estimation of FRP-strengthened Corroded Concrete Columns
Journal of Soft Computing in Civil Engineering

"The Enigmas of the Riemann Hypothesis" by Julio Chai
"The Enigmas of the Riemann Hypothesis" by Julio Chai"The Enigmas of the Riemann Hypothesis" by Julio Chai
"The Enigmas of the Riemann Hypothesis" by Julio Chai
Julio Chai

Influence line diagram for truss in a robust
Influence line diagram for truss in a robustInfluence line diagram for truss in a robust
Influence line diagram for truss in a robust
ParthaSengupta26

Android basics – Key Codes – ADB – Rooting Android – Boot Process – File Syst...
Android basics – Key Codes – ADB – Rooting Android – Boot Process – File Syst...Android basics – Key Codes – ADB – Rooting Android – Boot Process – File Syst...
Android basics – Key Codes – ADB – Rooting Android – Boot Process – File Syst...
ManiMaran230751

Influence line diagram in a robust model
Influence line diagram in a robust modelInfluence line diagram in a robust model
Influence line diagram in a robust model
ParthaSengupta26

world subdivision.pdf...................
world subdivision.pdf...................world subdivision.pdf...................
world subdivision.pdf...................
bmmederos12

Kevin Corke Spouse Revealed A Deep Dive Into His Private Life.pdf
Kevin Corke Spouse Revealed A Deep Dive Into His Private Life.pdfKevin Corke Spouse Revealed A Deep Dive Into His Private Life.pdf
Kevin Corke Spouse Revealed A Deep Dive Into His Private Life.pdf
Medicoz Clinic

Proposed EPA Municipal Waste Combustor Rule
Proposed EPA Municipal Waste Combustor RuleProposed EPA Municipal Waste Combustor Rule
Proposed EPA Municipal Waste Combustor Rule
AlvaroLinero2

fy06_46f6-ht30_22_oil_gas_industry_guidelines.ppt
fy06_46f6-ht30_22_oil_gas_industry_guidelines.pptfy06_46f6-ht30_22_oil_gas_industry_guidelines.ppt
fy06_46f6-ht30_22_oil_gas_industry_guidelines.ppt
sukarnoamin

Air Filter Flat Sheet Media-Catalouge-Final.pdf
Air Filter Flat Sheet Media-Catalouge-Final.pdfAir Filter Flat Sheet Media-Catalouge-Final.pdf
Air Filter Flat Sheet Media-Catalouge-Final.pdf
FILTRATION ENGINEERING & CUNSULTANT

Fresh concrete Workability Measurement
Fresh concrete  Workability  MeasurementFresh concrete  Workability  Measurement
Fresh concrete Workability Measurement
SasiVarman5

ISO 10121-Flat Sheet Media-Catalouge-Final.pdf
ISO 10121-Flat Sheet Media-Catalouge-Final.pdfISO 10121-Flat Sheet Media-Catalouge-Final.pdf
ISO 10121-Flat Sheet Media-Catalouge-Final.pdf
FILTRATION ENGINEERING & CUNSULTANT

HVAC Air Filter Equipment-Catalouge-Final.pdf
HVAC Air Filter Equipment-Catalouge-Final.pdfHVAC Air Filter Equipment-Catalouge-Final.pdf
HVAC Air Filter Equipment-Catalouge-Final.pdf
FILTRATION ENGINEERING & CUNSULTANT

Application Security and Secure Software Development Lifecycle
Application  Security and Secure Software Development LifecycleApplication  Security and Secure Software Development Lifecycle
Application Security and Secure Software Development Lifecycle
DrKavithaP1

MODULE 4 BUILDING PLANNING AND DESIGN SY BTECH HVAC SYSTEM IN BUILDING
MODULE 4 BUILDING PLANNING AND DESIGN SY BTECH HVAC SYSTEM IN BUILDINGMODULE 4 BUILDING PLANNING AND DESIGN SY BTECH HVAC SYSTEM IN BUILDING
MODULE 4 BUILDING PLANNING AND DESIGN SY BTECH HVAC SYSTEM IN BUILDING
Dr. BASWESHWAR JIRWANKAR

Enhanced heart disease prediction using SKNDGR ensemble Machine Learning Model
Enhanced heart disease prediction using SKNDGR ensemble Machine Learning ModelEnhanced heart disease prediction using SKNDGR ensemble Machine Learning Model
Enhanced heart disease prediction using SKNDGR ensemble Machine Learning Model
IRJET Journal

"The Enigmas of the Riemann Hypothesis" by Julio Chai
"The Enigmas of the Riemann Hypothesis" by Julio Chai"The Enigmas of the Riemann Hypothesis" by Julio Chai
"The Enigmas of the Riemann Hypothesis" by Julio Chai
Julio Chai

Influence line diagram for truss in a robust
Influence line diagram for truss in a robustInfluence line diagram for truss in a robust
Influence line diagram for truss in a robust
ParthaSengupta26

Android basics – Key Codes – ADB – Rooting Android – Boot Process – File Syst...
Android basics – Key Codes – ADB – Rooting Android – Boot Process – File Syst...Android basics – Key Codes – ADB – Rooting Android – Boot Process – File Syst...
Android basics – Key Codes – ADB – Rooting Android – Boot Process – File Syst...
ManiMaran230751

Influence line diagram in a robust model
Influence line diagram in a robust modelInfluence line diagram in a robust model
Influence line diagram in a robust model
ParthaSengupta26

world subdivision.pdf...................
world subdivision.pdf...................world subdivision.pdf...................
world subdivision.pdf...................
bmmederos12

Kevin Corke Spouse Revealed A Deep Dive Into His Private Life.pdf
Kevin Corke Spouse Revealed A Deep Dive Into His Private Life.pdfKevin Corke Spouse Revealed A Deep Dive Into His Private Life.pdf
Kevin Corke Spouse Revealed A Deep Dive Into His Private Life.pdf
Medicoz Clinic

Proposed EPA Municipal Waste Combustor Rule
Proposed EPA Municipal Waste Combustor RuleProposed EPA Municipal Waste Combustor Rule
Proposed EPA Municipal Waste Combustor Rule
AlvaroLinero2

fy06_46f6-ht30_22_oil_gas_industry_guidelines.ppt
fy06_46f6-ht30_22_oil_gas_industry_guidelines.pptfy06_46f6-ht30_22_oil_gas_industry_guidelines.ppt
fy06_46f6-ht30_22_oil_gas_industry_guidelines.ppt
sukarnoamin

Fresh concrete Workability Measurement
Fresh concrete  Workability  MeasurementFresh concrete  Workability  Measurement
Fresh concrete Workability Measurement
SasiVarman5


Introduction to HTML-CSS-Javascript.pptx

  • 2. Goals Introduction to web technologies: ● HTML to create the document structure and content ● CSS to control is visual aspect ● Javascript for interactivity
  • 3. Tools What do we need to start: ● a good web-browser (Chrome or Firefox) ● a good text editor like: ○ VSCode (cross platform) ○ Notepad++ (win) ○ textWrangler (osx) ○ sublime text (cross platform) ○ ecode (cross platform) ● the example HTML code to start
  • 4. How can I test my code Just open the index.html from the template in your text editor and in your browser. When you do any change to the code, check it in the browser by pressing F5 (refresh site) To open the developer tools press: Windows: Control + Shift + I or OSX: Command + Opt + I Other tools are online editors like scratchpad or htmledit
  • 5. Anatomy of a Browser
  • 6. Inside a browser Browsers have very differentiate parts. We are interested in two of them: ● the Rendering Engine (in charge of transforming our HTML+CSS in a visual image). ● The Javascript Interpreter (also known as VM), in charge of executing the Javascript code.
  • 8. Browsers as a renderer Browser's act as a renderer that takes documents and construct a visual representation of them. Starting with the most simple one, a text document, it will try to visualize it. You can try, drop any .txt file into your browser to visualize it. The problem is that text documents without any formatting tend to be hard to read for the user (and quite boring). That's why HTML was created, to give text some format.
  • 9. Markup language There are many markup languages that add special tags into the text that the renderer wont show but use to know how to display the text. In HTML this tags use the next notation: My name is <b>Javi</b>
  • 10. HTML HTML means Hyper Text Markup Language. The HTML allow us to define the structure of a document or a website. HTML is NOT a programming language, it’s a markup language, which means its purpose is to give structure to the content of the website, not to define an algorithm. It is a series of nested tags (it is a subset of XML) that contain all the website information (like texts, images and videos). Here is an example of tags: <title>This is a title</title> The HTML defines the page structure. A website can have several HTMLs to different pages. <html> <head> </head> <body> <div> <p>Hi</p> </div> </body> </html>
  • 11. HTML: basic rules Some rules about HTML: ● It uses XML syntax (tags with attributes, can contain other tags). <tag_name attribute="value"> content </tag_name> ● It stores all the information that must be shown to the user. ● There are different HTML elements for different types of information and behaviour. ● The information is stored in a tree-like structure (nodes that contain nodes inside) called DOM (Document Object Model). ● It gives the document some semantic structure (pe. this is a title, this is a section, this is a form) which is helpful for computers to understand websites content. ● It must not contain information related to how it should be displayed (that information belongs to the CSS), so no color information, font size, position, etc.
  • 12. HTML: syntax example <div id="main"> <!-- this is a comment --> This is text without a tag. <button class="mini">press me</button> <img src="me.png" /> </div>
  • 13. HTML: syntax example <div id="main"> <!-- this is a comment --> This is text without a tag. <button class="mini">press me</button> <img src="me.png" /> </div> Tag name attribute s commen t text tag self-closing tag
  • 14. DOM is a tree Every node can only have one parent, and every node can have several children, so the structure looks like a tree.
  • 16. Although there are lots of tags in the HTML specification, 99% of the webs use a subset of HTML tags with less that 10 tags, the most important are: ● <div>: a container, usually represents a rectangular area with information inside. ● <img/>: an image ● <a>: a clickable link to go to another URL ● <p>: a text paragraph ● <h1>: a title (h2,h3,h4 are titles of less importance) ● <input>: a widget to let the user introduce information ● <style> and <link>: to insert CSS rules ● <script>: to execute Javascript ● <span>: a null tag (doesn't do anything), good for tagging info HTML: main tags
  • 17. HTML: other interesting tags There are some tags that could be useful sometimes: ● <button>: to create a button ● <audio>: for playing audio ● <video>: to play video ● <canvas>: to draw graphics from javascript ● <iframe>: to put another website inside ours
  • 18. HTML: wrapping the info We use HTML tags to wrap different information on our site. The more structure has the information, the easier will be to access it and present it. We can change the way the information is represented on the screen depending on the tags where it is contained, so we shouldn't be worried about using too many tags.
  • 19. HTML: tagging correctly Try to avoid doing this: <div > Titl e Here is some content Here is more content </div> Do this instead <div> <h1>Title</h1> <p>Here is content.</p> <p>Here is more content</p> </div> DONT DO THIS
  • 20. HTML good use It is good to have all the information properly wrapped in tags that give it some semantics. We also can extend the code semantics by adding extra attributes to the tags: ● id: tells a unique identifier for this tag ● class: tells a generic identifier for this tag <div id="profile-picture" class="mini-image">...</div>
  • 21. HTML references HTML Reference: a description of all HTML tags. The 25 Most used tags: a list with information of the more common tags. HTML5 Good practices: some tips for starters
  • 23. CSS CSS allows us to specify how to present (render) the document info stored in the HTML. Thanks to CSS we can control all the aspects of the visualization and some other features: ● Colors: content, background, borders ● Margins: interior margin, exterior margin ● Position: where to put it ● Sizes: width, height ● Behaviour: changes on mouse over
  • 24. CSS example * { color: blue; /*a comment */ margin: 10px; font: 14px Tahoma; } This will change all the tags in my web ( ‘*‘ means all) to look blue with font Tahoma with 14px, and leaving a margin of 10px around.
  • 25. CSS fields Here is a list of the most common CSS fields and an example: ● color: #FF0000; red; rgba(255,00,100,1.0); //different ways to specify colors ● background-color: red; ● background-image: url('file.png'); ● font: 18px 'Tahoma'; ● border: 2px solid black; ● border-top: 2px solid red; ● border-radius: 2px; //to remove corners and make them more round ● margin: 10px; //distance from the border to the outer elements ● padding: 2px; //distance from the border to the inner elements ● width: 100%; 300px; 1.3em; //many different ways to specify distances ● height: 200px; ● text-align: center; ● box-shadow: 3px 3px 5px black; ● cursor: pointer; ● display: inline-block; ● overflow: hidden;
  • 26. CSS how to add it There are four ways to add CSS rules to your website: ● Inserting the code inside a style tag <style> p { color: blue } </style> ● Referencing an external CSS file <link href="style.css" rel="stylesheet" /> ● Using the attribute style on a tag <p style="color: blue; margin: 10px"> ● Using Javascript (we will see this one later).
  • 27. CSS selectors Let's start by changing the background color of one tag of our website: div { background-color: red; } This CSS rule means that every tag DIV found in our website should have a red background color. Remember that DIVs are used mostly to represent areas of our website. We could also change the whole website background by affecting the tag body: body { background-color: red; }
  • 28. CSS selectors What if we want to change one specific tag (not all the tags of the same type). We can specify more precise selectors besides the name of the tag. For instance, by class or id. To specify a tag with a given class name, we use the dot: p.intro { color: red; } This will affect only the tags p with class name intro: <p class="intro">
  • 29. CSS Selectors There are several selectors we can use to narrow our rules to very specific tags of our website. The main selectors are: ● tag name: just the name of the tag ○ p { ... } //affects to all <p> tags ● dot (.): affects to tags with that class ○ p.highlight { ... } //affects all <p> tags with class="highlight" ● sharp character (#): specifies tags with that id ○ p#intro { ... } //affects to the <p> tag with the id="intro" ● two dots (:): behaviour states (mouse on top) ○ p:hover { ... } //affects to <p> tags with the mouse over ● brackets ([attr='value']): tags with the attribute attr with the value 'value' ○ input[type="text"] {...} // affects to the input tags of the type text
  • 30. CSS Selectors You can also specify tags by its context, for example: tags that are inside of tags matching a selector. Just separate the selectors by an space: div#main p.intro { ... } This will affect to the p tags of class intro that are inside the tag div of id main <div id="main"> <p class="intro">....</p> ← Affects this one </div> <p class="intro">....</p>← but not this one
  • 31. CSS Selectors And you can combine selectors to narrow it down more. div#main.intro:hover { ... } will apply the CSS to the any tag div with id main and class intro if the mouse is over. And you do not need to specify a tag, you can use the class or id selectors without tag, this means it will affect to any node of id main #main { ... }
  • 32. CSS Selectors If you want to select only elements that are direct child of one element (not that have an ancestor with that rule), use the > character: ul.menu > li { ... } Finally, if you want to use the same CSS actions to several selectors, you can use the comma , character: div, p { … } ← this will apply to all divs and p tags
  • 33. HTML arrange It is important to understand how the browser arranges the elements on the screen. Check this tutorial where it explains the different ways an element can be arranged on the screen. You can change the way elements are arranged using the display property: div { display: inline-block; }
  • 34. Box Model It is important to note that by default any width and height specified to an element will not take into account its margin, so a div with width 100px and margin 10px will measure 120px on the screen, not 100px. This could be a problem breaking your layout. You can change this behaviour changing the box model of the element so the width uses the outmost border: div { box-sizing: border; }
  • 35. Layout One of the hardest parts of CSS is construing the layout of your website (the structure inside the window) . By default HTML tends to put everything in one column, which is not ideal. There has been many proposals in CSS to address this issue (tables, fixed divs, flex, grid, …).
  • 36. Flexbo x The first big proposal to address the layout was the flexbox model. This model allows to arrange stuff in one direction (vertically or horizontally) very easily. You can even choose to arrange from right to left (reverse). It can also be used to arrange a series of elements in different rows. Check the tutorial for more info. HTML <div class="box"> <div>One</div> <div>Two</div> <div>Three <br>first line <br>second line </div> </div> CSS .box { display: flex; }
  • 37. Grid system Because most sites are structured in a grid, I recommend to use the CSS Grid system. We just assign how many rows/columns a div should use from the main grid and it will arrange automatically. Check this tutorial to create the site structure easily HTML <div class="grid-container"> <div class="grid-item1">1</div> <div class="grid-item2">2</div> </div> CSS .grid-container { display: grid; grid-template- rows: 100px 100px; grid-template-columns: 100px 100px 100px; grid-gap: 5px; } .grid-item1 { background: blue; border: black 5px solid; grid-column- start: 1;
  • 38. Fullscreen divs Sometimes we want to have a div that covers the whole screen (to make a webapp), instead of a scrolling website (more like regular documents). In that case remember to use percentages to define the size of elements, but keep in mind that percentages are relative to the element's parent size, so you must set the size to the <body> and <html> element to use 100%. CSS html, body { width: 100%; height: 100%; } div { margin: 0; padding: 0; } #main { width: 100%; height: 100%; }
  • 39. Trick to center Centering divs can be hard sometimes, use this trick: .horizontal-and-vertical- centering { display: flex; justify-content: center; align-items: center; }
  • 40. CSS further reading There are many more rules for selectors. Check some of the links to understand them better. One line layouts tutorials Understanding the Box Model: a good explanation of how to position the information on your document. All CSS Selectors: the CSS selectors specification page. CSS Transition: how to make animations just using CSS TailwindCSS: a CSS Framework
  • 42. Interactivit y Once the web was already being used they realize people wanted to interact with the websites in a more meaningful way. So they added an Interpreter to execute a script language that could modify the content of the web dynamically. Brendan Eich was tasked to develop it in one week and it has become one of the most important languages.
  • 43. Javascript A regular programming language, easy to start, hard to master. Allows to give some interactivity to the elements on the web. Syntax similar to C or Java but with no types. You can change the content of the HTML or the CSS applied to an element. You can even send or retrieve information from the internet to update the content of the web without reloading the page. var my_number = 10; function say( str ) { console.log( str ); } say("hello");
  • 44. Javascript: insert code There is three ways to execute javascript code in a website: ● Embed the code in the HTML using the <script> tag. <script> /* some code */ </script> ● Import a Javascript file using the <script> tag: <script src="file.js" /> ● Inject the code on an event inside a tag: <button onclick="javascript: /*code*/">press me</button>
  • 45. Javascript: Syntax Very similar to C++ or Java but much simpler. var my_number = 10; //this is a comment var my_string = "hello"; var my_array = [10,20,"name",true]; var my_object = { name: "javi", city: "Barcelona" }; function say( str ) { for(var i = 0; i < 10; ++i) console.log(" say: " + str );
  • 46. Javascript example <html> <body> <h1>This is a title</h1> <script> var title = document.querySelector("h1"); title.innerHTML = "This is another title"; </script> </body> </html>
  • 47. Javascript API Javascript comes with a rich API to do many things like: ● Access the DOM (HTML nodes) ● Do HTTP Requests ● Play videos and sounds ● Detect user actions (mouse move, key pressed) ● Launch Threads ● Access the GPU, get the Webcam image, ... And the API keeps growing with every new update of the standard. Check the WEB API reference to know more
  • 48. Javascript: retrieving element You can get elements from the DOM (HTML tree) using different approaches. ● Crawling the HTML tree (starting from the body, and traversing its children) ● Using a selector (like in CSS) ● Attaching events listeners (calling functions when some actions are performed)
  • 49. Javascript: crawling the DOM From javascript you have different variables that you can access to get information about the website: ● document: the DOM information (HTML) ● window: the browser window The document variable allows to crawl the tree: document.body.children[0] // returns the first node inside body tag
  • 50. Javascript: using selectors You can retrieve elements using selectors: var nodes = document.querySelectorAll("p.intro"); will return an array with all <p class="intro"> nodes in the web. Or if we have already a node and we want to search inside: var node = mynode.querySelectorAll("p.intro")
  • 51. Javascript: modify nodes From JS you can change the attributes mynode.id = "intro"; //sets an id mynode.className = "important"; //set class mynode.classList.add("good"); //to add to the current classes Change the content mynode.innerHTML = "<p>text to show</p>"; //change content Modify the style (CSS) mynode.style.color = "red"; //change any css properties or add the behaviour of a node
  • 52. Javascript: create nodes Create elements: var element = document.createElement("div"); And attach them to the DOM: document.querySelector("#main").appendChild( elemen t ); Or remove it from its parent: element.remove(); You can clone an element also easily: var cloned = element.cloneNode(true);
  • 53. Javascript: hide and show elements Sometimes it may be useful to hide one element or show another. You can change an element CSS directly by accessing its property style. To avoid being displayed on the web change display to "none" element.style.display = "none"; //hides elements from being rendered element.style.display = ""; //displays it again
  • 54. Using Inputs If you want the user to be able to input some text we use the tag <input>: <input type="text"/> There are other inputs, you can check this list. From Javascript we can attach events like "click" or "keydown". To read or modify the content of the input: my_input_element.value = ""; //this will clear the text inside the input
  • 55. Example of a website HTML in index.html <link href="style.css" rel="stylesheet"/> <h1>Welcome</h1> <p> <button>Click me</button> </p> <script src="code.js"/> CSS in style.css h1 { color: #333; } button { border: 2px solid #AAA; background- color: #555; } Javascript in code.js //fetch the button from the DOM var button = document.querySelector("button"); //attach and event when the user clicks it button.addEventListener("click", myfunction); //create the function that will be called when the button is pressed function myfunction() { //this shows a popup window alert("button clicked!"); }
  • 56. Execution flow It is important to have a clear understanding of the execution flow of your code. Scripts are executed when the html is being parsed. Be careful accessing the DOM as the DOM won’t contain all until all the HTML is parsed. It is good practice to start your code with an init function called at the end of your HTML. <script> var main = document.querySelector("#main"); //main here is null, as the element does //exist yet </script> <div id="main"></div> <script> var main = document.querySelector("#main"); //main now is the right element </script>
  • 57. Further info API References: DevDocs.io Selectors: MDN Tutorial To learn Javascript. http://codeacademy.co m To learn jQuery:
